Steel ball Sorting Machine (HRT-1202)
2016-10-31
Products model:
HRT-1202
Range of application:
This new roller sorting machine is mainly used for selecting size precision of the steel balls automatically. Sorting range is from 0.1mm to 2.0mm. The precision ≤0.001mm is very applicable to size precision selecting of difference diameter steel balls. During rough sorting period, it also can be used to pick different balls, scrapped parts and surface defected balls out. Meanwhile, it is applicable to various sizes of hi-precision metal and electronic components. Click “Read More” for structural features and main technical parameter about HRT-1202 Steel ball Sorting Machine, with the detailed technical staff ball sorter operation video.
Structural Features:
This machine is designed by totally enclosed type, shapely and clean, good dustproof performance. There are total 2 groups sorting rollers to operate,which being 2 times efficiency compare with traditional machine, but 1/2 labor cost only, equipped with a special classified collecting box and the corresponding sensor, also designed with moisture-proof device. Our latest patented roller designing improve precision sorting to ≦0.001mm. The auto-input material feeding system has been adopted to this new machine, which is capable for adjusting the feeding speed and sorting different size steel balls.
Main Technical Parameter:
Ball size φ0.1mm--φ2mm Precision ≤0.001mm Roller effective classification length 460mm Diameter of roller φ35mm Velocity modulation range of the roller 0-260turn/minute Vibration material input capacity 10kg Motor total power 120W Pulling force of vibration electromagnet ≥2.7KN Source of electricity 220V/50Hz Overall size (L × W × H) 910x680x1035mm Net weight 160kg
Detailed technical staff ball sorter operation video of HRT-1202 Steel ball Sorting Machine:
(Please contact for Video Password , thank you!)
——Zhongshan HRT Precision Steel Ball Co., Ltd.
