◆Main Technical Parameter

Ball size: φ0.1mm--φ2mm

Sorting Precision: ≤0.003mm

Roller Precision: ≤0.001mm

Roller effective classification length: 460mm

Diameter of roller: φ35mm

Velocity modulation range of the roller: 0-260turn/minute

Vibration material input capacity: 10kg

Motor total power: 120W

Pulling force of vibration electromagnet: ≥2.7KN

Source of electricity: 220V/50Hz

Overall size (L × W × H): 910x680x1035mm

Net weight: 160kg

This roller sorting machine is mainly used for selecting size precision of the steel balls automatically. The precision ≤0.001mm is very applicable to size precision selecting of difference diameter steel balls. During rough sorting period, it also can be used to pick different balls, scrapped parts and surface defected balls out. Meanwhile, it is applicable to various sizes of hi-precision metal and electronic components .
